 Mixing,
inputting powder, processing board,
bagging, metal processing, inputting
air-supply, sanding, cutting cast iron
ware, blending, drilling, severing,
cutting, crashing, cutting stone |
| |
 |
TURBO
BLOWER
Realized vibration-free and low-noise
as increasingabsorption power
with decreasing idling weight
and starting load on account of
applying the domestic beginning
of aluminum alloy, and as working
with ultraprecision press mold
and electronic balancing.
COTTON
POLE FILTER WITH HIGH RATIO OF
COLLECTION
High efficiency of collection
without remaining solid material
after burning on account of adoption
cotton quality filter to collect
high-priced dust in processing
precious metal. |
|
|
COMPACT
FILTER EASILY CHANGEABLE
Very easily changeable owing to
adoption of filter set separated immediately
as only unfastening with 2 bolts star-shaped
of DOOR side without tool. The way of
shaking filter is manual.
DUST
BOX
Dust Box under the Dust Collector is
easy to collect dust as easily changeable
sliding type. |
 |
|
|
| |
| |
 |
| TYPE |
AM-100 |
AM-200 |
AM-200-TNA |
AM-300 |
AP-500 |
| POWER
SOURCE |
220V
1P AC, 220V/380V 3P 60Hz,
440V(Option), 50Hz(Option) |
220/380V
3P AC 60Hz,
440V(Option),50Hz(Option) |
|
B
L
O
W
E
R |
VOLUME OF
WIND (m©ø/min) |
12 |
25 |
25 |
40 |
60 |
|
CONSTANT
PRESSURE (mmAq) |
230 |
|
MOTOR (Kw) |
0.75 |
1.5 |
1.5 |
2.2 |
4.0 |
|
B
A
G
F
I
L
T
E
R |
SIZE (WxL) |
435
x 600 |
|
QUANTITY (Poket) |
10 |
20 |
20 |
30 |
40 |
|
FILTRATION
SIZE (m©÷) |
4.5 |
9.0 |
9.0 |
13.5 |
18.0 |
| MATERIALS |
COTTON
CLOTH |
| NON-WOVEN
FABRIC |
HAND
SHAKING |
|
S
I
Z
E
|
A
(mm) |
450 |
650 |
1,250 |
850 |
1,150 |
| B
(mm) |
600 |
650 |
650 |
650 |
700 |
| C
(mm) |
1,400 |
1,480 |
1,480 |
1,535 |
1,575 |
| ¨ªD
(mm) |
150 |
200 |
- |
250 |
250 |
| E
(mm) |
205 |
205 |
- |
205 |
205 |
| F
(mm) |
737 |
737 |
- |
737 |
737 |
| ¨ªG
(mm) |
150 |
250 |
250 |
300 |
300 |
| H
(mm) |
128 |
128 |
128 |
128 |
128 |
| CAPACITY
OF DUST BOX (l) |
15 |
24 |
68 |
30 |
42 |
| ROUGH
WEIGHT (Kg) |
100 |
150 |
220 |
180 |
270 |
|
| |
|
|
| |
|
|
